Arapaho (AT-14) Class: Photographs

These photographs were selected to show the original configuration of this class and major subsequent modifications. For most classes many other photographs exist.
For more complete online collections of U. S. Navy ship photographs see in particular the NHHC Online Library of Selected Images and the NavSource Photo Archive.

Click on the small photograph to prompt a larger view of the same image.

USS Arapaho (Tug No. 14)

At San Diego circa 1915-1916.
The protected cruiser Raleigh (Cruiser No. 8) is in the background.

Photo No. NH 92206
Source: U.S. Naval History and Heritage Command


USS Wando (Tug No. 17)

Off the Charleston, S.C., Navy Yard on 22 May 1917.

Photo No. NH 43679
Source: U.S. Naval History and Heritage Command


"USS Chemung, Tug No. 18" ... March 12, 1918

Design plan for the tug Chemung (Tug No. 18) prepared by the Bureau of Construction and Repair's Preliminary Design staff on 12 March 1918, apparently for comparison with designs of new tugs then being developed for consideration for near-term construction. Chemung was designed for the U.S. Navy and built of steel at Norfolk Navy Yard during 1914 to 1917. Originally named Pocahontas, the vessel was renamed on 1 September 1917. Chemung was decommissioned in 1926 and discarded in 1937.
This plan provides two 3-inch guns, reciprocating steam machinery, and a speed of 11 knots in a ship 115 feet long on the waterline, 25 feet in beam, and with a normal displacement of 555 tons.

The original plan is in the 1911-1925 "Spring Styles Book" of the Bureau of Construction & Repair.

Photo No. S-584-077
Source: U.S. Naval History and Heritage Command (from the Online Library).


USS Tillamook (AT-16)

In dry dock after World War I, probably at the Mare Island Navy Yard where she served her entire career.

Photo No. NH 43727
Source: U.S. Naval History and Heritage Command


USS Mohave (AT-15)

At the Boston Navy Yard ca. 1924.
USS Bridgeport (AD-10) and USS Constitution (IX-21) are in the background.

Photo No. NH 45949
Source: U.S. Naval History and Heritage Command


USS Chemung (AT-18)

Probably shown after World War I.

Photo No. NH 57884
Source: U.S. Naval History and Heritage Command
